Description
Features of the P9521-000-115-0-EN ELGO Electric Machine Controller:
- 2 or 3 speed positioning
- Absolute and incremental positioning modes
- Program line operation (10 lines)
- Operation in Single positioning mode
- Manual inching mode (fast and slow speed)
- Quantity counting with completed output
- Flexible multiplier for Display calibration
- Datum precept routines
- Tool offset compensation in incremental mode
- Incremental error compensation
- Backlash compensation
- Tolerance window blanking
- Encoder and drive failure detection
- Maximum Encoder frequency 20 kHz
The unit is suitable for operation with any type of 2 or 3 speed bi-directional drive or any variable speed drive with 1,2 or 4 quadrant of control. The performance and accuracy obtained is dependent on the type of drive chosen. The outputs for stepped speed drives are relays.
